Siemens 5SJ63106KS 5SJ6310-6KS zaštitna sklopka za vodove 10 A <

(0)

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

Cijena na upit

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Izvedba	Minijaturni prekidač 5SJ6
Nazivni napon	400
Pogonski razred	3
RoHS-konforno	Da
Nazivna struja - zaokružena	10
Nazivna struja	10
dim.	(Š x V x D) 54 x 90 x 76 mm
Sadržaj	1
Dubina	76
Visina	90
Širina	54
Broj polova	3
Karakteristike okidanja	b
Pogonski napon	440
Voltage type	AC/DC
Built-in depth	70.0
Rated current	10
Rated voltage	400
Frequency	50-60
Release characteristic	B
Rated insulation voltage Ui	440
Current limiting class	3
Over voltage category	3
Pollution degree	2
Width in number of modular spacings	3
Degree of protection (IP)	IP20
Number of protected poles	3
Concurrently switching neutral conductor	ne
Suitable for flush-mounted installation	ne
Additional equipment possible	ne
Number of poles (total)	3
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6.0
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	6.0
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	6.0
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	6.0
ECl@ss System Name	27-14-19-01
ECl@ss System Name	ECLASS-9.1
ETIM FeatureGroupID	EC000042
ETIM System Name	ETIM-7.0
Vrsta proizvoda	zaštitna sklopka za vodove
