Siemens 6AV7260-2DN20-1BC0 PLC komunikacijski modul
- Kataloški br:
- 1681703 - 62
- Oznaka:
- 6AV72602DN201BC0
- EAN:
- 2050005425139
- Kataloški br:
- 1681703 - 62
- Oznaka:
- 6AV72602DN201BC0
- EAN:
- 2050005425139
Siemens 6AV7260-2DN20-1BC0 PLC komunikacijski modul
Cijena na upit
0.00 KM
Komada
Prodaja i slanje od:
Architektengruppe S71 d.o.o.
Komada
Tehničke specifikacije
Tehničke specifikacije
| Sučelja | 3 |
| Tip | 6AV7260-2DN20-1BC0 |
| Proizvođač-br. dijela | 6AV72602DN201BC0 |
| Sadržaj | 1 |
| Montaža | Za vodoravnu i okomitu montažu |
| Serija | Siemens-HMI |
| Suitable for safety functions | ne |
| Screen diagonal | 55.88 |
| Operating temperature | 5.0-45.0 |
| Supporting protocol for LON | ne |
| Number of HW-interfaces serial TTY | 0 |
| Supporting protocol for ASI | ne |
| Supporting protocol for PROFIBUS | da |
| Supporting protocol for CAN | ne |
| Supporting protocol for INTERBUS | ne |
| Supporting protocol for KNX | ne |
| Supporting protocol for Modbus | ne |
| Supporting protocol for Data-Highway | ne |
| Supporting protocol for DeviceNet | ne |
| Supporting protocol for SUCONET | ne |
| With touch screen | da |
| With floppy disc drive | ne |
| Customer individual configuration | da |
| Number of free AGP-slots | 0 |
| Number of free PCI-slots | 2 |
| Number of free ISA-slots | 0 |
| Number of free PCMCIA-slots | 0 |
| Number of HW-interfaces SCSI | 0 |
| Number of HW-interfaces PS2 | 0 |
| Width of the front | 560.0 |
| Height of the front | 380.0 |
| Supporting protocol for SERCOS | ne |
| Supporting protocol for INTERBUS-Safety | ne |
| Number of interfaces PROFINET | 3 |
| IO link master | ne |
| Supporting protocol for AS-Interface Safety at Work | ne |
| Supporting protocol for DeviceNet Safety | ne |
| Supporting protocol for Foundation Fieldbus | ne |
| Supporting protocol for PROFINET CBA | ne |
| Supporting protocol for PROFIsafe | ne |
| Supporting protocol for SafetyBUS p | ne |
| Radio standard GPRS | ne |
| Radio standard GSM | ne |
| Radio standard UMTS | ne |
| Vrsta proizvoda | PLC panel s računalom |
Opis
Opis
SIMATIC IPC677D, 2x10 / 100/1000 Mbps Ethernet 4x USB V3.0, 1x serijski (COM1) nadzor, nadzor temperature i ventilatora RAID regulator na brodu 22 "Touch (1920x1080) s prednjim USB jezgrom I3-4330TE (2C / 4T, 2,4 GHz, 4 MB cache, VT-X) Solid State Drive 240 GB 320 GB HDD SATA (2,5 ") 4 GB DDR3 1600 DIMM 2x PCI 2x USB ADDITIVE (zauzimaju 1 utor) Windows 7 Ultimate 64 bit SP1, MUI (de, en, fr, sp, it) SIMATIC IPC DIAGMONITOR V4.5 i Image & Partition Creator V3.4 zatvorena AC 110 / 230V industrijska napajanja s NAMUR mrežnim kabelom Europe
