WAGO 750-671 PLC upravljač koračnog motora 750-671 1 St.
- Kataloški br:
- 192075 - 62
- Oznaka:
- 750-671
- EAN:
- 4045454853310
- Kataloški br:
- 192075 - 62
- Oznaka:
- 750-671
- EAN:
- 4045454853310
WAGO 750-671 PLC upravljač koračnog motora 750-671 1 St.
980.00 KM
Komada
Prodaja i slanje od:
Architektengruppe S71 d.o.o.
980.00 KM
sa PDV
Troškovi dostave
Komada
Tehničke specifikacije
Tehničke specifikacije
| Sučelje | klemmen |
| Tip | 750-671 |
| Broj ulaza maks. | 2 |
| Broj izlaza maks. | 2 |
| Radni napon | 24 V/DC |
| Visina | 65 mm |
| Dužina | 100 mm |
| Širina | 51 mm |
| Maks. temperatura okoline | +55 °C |
| Min. temperatura okoline | 0 °C |
| dim. | (D x Š x V) 100 x 51 x 65 mm |
| Proizvođač-br. dijela | 750-671 |
| Težina | 56 g |
| Width | 12 |
| Height | 100 mm |
| Depth | 67.8 mm |
| Suitable for safety functions | FALSE |
| Voltage type (supply voltage) | DC |
| Supporting protocol for LON | FALSE |
| Number of HW-interfaces RS-232 | 0 |
| Number of HW-interfaces RS-422 | 0 |
| Number of HW-interfaces RS-485 | 0 |
| Number of HW-interfaces parallel | 0 |
| Number of HW-interfaces other | 0 |
| Supporting protocol for TCP/IP | FALSE |
| Supporting protocol for ASI | FALSE |
| Supporting protocol for PROFIBUS | FALSE |
| Supporting protocol for CAN | FALSE |
| Supporting protocol for INTERBUS | FALSE |
| Supporting protocol for KNX | FALSE |
| Supporting protocol for Modbus | FALSE |
| Supporting protocol for Data-Highway | FALSE |
| Supporting protocol for DeviceNet | FALSE |
| Supporting protocol for SUCONET | FALSE |
| Supporting protocol for other bus systems | FALSE |
| Suitable for rail mounting | TRUE |
| Explosion safety category for gas | ATEX gas-ex-protection, Cat. 3G |
| Explosion safety category for dust | ATEX dust-ex-protection, Cat. 3D |
| Appendant operation agent (Ex ia) | FALSE |
| Appendant operation agent (Ex ib) | FALSE |
| Degree of protection (IP) | IP20 |
| Supporting protocol for SERCOS | FALSE |
| Supporting protocol for INTERBUS-Safety | FALSE |
| Number of interfaces PROFINET | 0 |
| Supporting protocol for AS-Interface Safety at Work | FALSE |
| Supporting protocol for DeviceNet Safety | FALSE |
| Supporting protocol for EtherNet/IP | FALSE |
| Supporting protocol for Foundation Fieldbus | FALSE |
| Supporting protocol for PROFINET CBA | FALSE |
| Supporting protocol for PROFINET IO | FALSE |
| Supporting protocol for PROFIsafe | FALSE |
| Supporting protocol for SafetyBUS p | FALSE |
| Supply voltage DC | 24-24 V |
| Vrsta proizvoda | PLC upravljač koračnog motora |
Opis
Opis
24 V / 1,0,208333333333333 svijetlo siva.
Ovaj tekst je strojno preveden.
Ovaj tekst je strojno preveden.
