LAPP 0012346/100 priključni vod 3 x 1 mm² 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 13.07.2025 do 15.07.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

1,170.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Broj žica	3 x
Poprečni presjek (po žili)	1 mm²
Presjek	3 x 1 mm²
Vanjski Ø	7.2 mm
Sadržaj	100 m
Nazivni napon	500 V
Nazivni napon U0	300 V
Proizvođač-br. dijela	0012346/100
Tip	ÖLFLEX® 500 P 3G1
Nominal cross section conductor	1 mm²
Material core insulation	Other
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Orange
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Conductor category	Class 6 = very flexible
Permitted cable outer temperature after assembling without vibration	-50-80 °C
Nominal voltage U0	300 V
Number of cores	3
Outer diameter approximate	7.2 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application/free movement	72.0 mm
Min. permitted bending radius, stationary application/permanent installation	28.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	TRUE
Vrsta proizvoda	priključni vod
