LAPP 0027855/100 podatkovni kabel UNITRONIC® FD siva 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 17.07.2025 do 19.07.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

-29 %

238.40 KM335.00 KM

Štedite 96.60 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	UNITRONIC® FD
Broj žica	2 x
Vanjski Ø	4 mm
Boja	siva
Sadržaj	100 m
Bez halogena	ne
Proizvođač-br. dijela	0027855/100
Izolacijski material	polivinilhlorid
Raspon temperature, fiksna instalacija (min.)	-40 °C
Raspon temperature, fiksna instalacija (maks.)	80 °C
Tip	UNITRONIC® FD 2x0,25
UV resistant	FALSE
Nominal cross section conductor	0.25 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Number of cores	2
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	4.3 mm
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application with forced guidance	21.5 mm
Min. permitted bending radius, moving application/free movement	21.5 mm
Min. permitted bending radius, stationary application/permanent installation	12.9 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	podatkovni kabel
