LAPP 0031409/1000 vod za prijenos podataka UNITRONIC® FD Li2YCY (TP) A crna 1000 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 17.07.2025 do 19.07.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

-27 %

24,698.90 KM34,060.00 KM

Štedite 9,361.10 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	UNITRONIC® FD Li2YCY (TP) A
Vanjski Ø	11 mm
Boja	crna
Sadržaj	1000 m
Bez halogena	ne
Proizvođač-br. dijela	0031409/1000
Izolacijski material	polivinilhlorid
Raspon temperature, fiksna instalacija (min.)	-40 °C
Raspon temperature, fiksna instalacija (maks.)	70 °C
Tip	UNITRONIC® FD Li2YCY (TP) A BE 6X2X0,5
UV resistant	FALSE
Nominal cross section conductor	0.5 mm²
Material core insulation	Other
Core identification	Colour
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-40-70 °C
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	11.3 mm
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
AWG size	Other
Min. permitted bending radius, stationary application/permanent installation	45.2 mm
Specification core insulation	Polyethylene (PE)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za prijenos podataka
