LAPP 0033305/500 podatkovni kabel UNITRONIC® LiYD11Y crna 500 m
- Kataloški br:
- 3357239 - 62
- Oznaka:
- 0033305/500
- EAN:
- 4044774741345
- Kataloški br:
- 3357239 - 62
- Oznaka:
- 0033305/500
- EAN:
- 4044774741345
LAPP 0033305/500 podatkovni kabel UNITRONIC® LiYD11Y crna 500 m
28 %
3,339.20 KM4,610.00 KM
Štedite 1,270.80 KM
Komada
Prodaja i slanje od:
Architektengruppe S71 d.o.o.
-28 %
3,339.20 KM4,610.00 KM
Štedite 1,270.80 KM
sa PDV
Troškovi dostave
Komada
Tehničke specifikacije
Tehničke specifikacije
| Tip kabela | UNITRONIC® LiYD11Y |
| Broj žica | 5 x |
| Vanjski Ø | 6 mm |
| Boja | crna |
| Sadržaj | 500 m |
| Bez halogena | ne |
| Proizvođač-br. dijela | 0033305/500 |
| Izolacijski material | poliuretan |
| Raspon temperature, fiksna instalacija (min.) | -40 °C |
| Raspon temperature, fiksna instalacija (maks.) | 80 °C |
| Tip | UNITRONIC® LiYD11Y 5x0,25 |
| UV resistant | TRUE |
| Nominal cross section conductor | 0.25 mm² |
| Material core insulation | Polyvinyl chloride (PVC) |
| Core identification | Colour |
| Colour outer sheath | Black |
| Conductor material | Copper |
| Material outer sheath | Polyurethane (PUR) |
| Permitted cable outer temperature after assembling without vibration | -40-80 °C |
| Number of cores | 5 |
| Halogen free according to EN IEC 60754-2 | FALSE |
| Low smoke according to EN IEC 61034-2 | FALSE |
| Outer diameter approximate | 6 mm |
| Low smoke (according to EN 61034-2) | FALSE |
| Conductor surface | Bare |
| Min. permitted bending radius, moving application/free movement | 60.0 mm |
| Min. permitted bending radius, stationary application/permanent installation | 36.0 mm |
| Specification core insulation | Other |
| Specification material outer sheath | Other |
| Cable geometry | Round |
| Core identification according to HD 308 S2 | FALSE |
| Vrsta proizvoda | podatkovni kabel |
