Kabeli za vučne lance

LAPP 0036939/500 vod za vučni lanac 0.09 mm² 500 m

Kataloški br:: 3363720 - 62
Oznaka:: 0036939/500
EAN:: 4056157138734

(0)

Kataloški br:: 3363720 - 62
Oznaka:: 0036939/500
EAN:: 4056157138734

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

-1 %

5,825.00 KM5,870.00 KM

Štedite 45.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Vrsta proizvoda	vod za vučni lanac
Poprečni presjek (po žili)	0.09 mm²
Presjek	0.09 mm²
Vanjski Ø	6.2 mm
Sadržaj	500 m
Nazivni napon	30 V
Proizvođač-br. dijela	0036939/500
Tip	ÖLFLEX® SERVO FD 798CP (10x2x28AWG)
Nominal cross section conductor	0.09 mm²
Core identification	Colour
Nominal voltage U	30 V
Colour outer sheath	Green
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Permitted cable outer temperature after assembling without vibration	-50-90 °C
Outer diameter approximate	6.2 mm
With protective conductor	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Tinned
AWG size	Other
Min. permitted bending radius, moving application with forced guidance	46.5 mm
Min. permitted bending radius, moving application/free movement	46.5 mm
Min. permitted bending radius, stationary application/permanent installation	24.8 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round

Opis

ÖLFLEX® SERVO FD 798CP (10x2x28AWG) kabel kodera; (10x2x28AWG); Extended-Line; 30 V; PUR; Oklopljeno; UL priznat; vučni lanac

Ovaj tekst je strojno preveden.
