Upravljački vodovi

LAPP kontrolni vod 1024416/100 100 m

Kataloški br:: 3476130 - 62
Oznaka:: 1024416/100
EAN:: 4044777070855

(0)

Kataloški br:: 3476130 - 62
Oznaka:: 1024416/100
EAN:: 4044777070855

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

2,185.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Proizvođač-br. dijela	1024416/100
Tip	ÖLFLEX® HEAT 125 C MC 3G1
Nominal cross section conductor	1 mm²
Material core insulation	Other
Core identification	Colour
Nominal voltage U	500 V
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-55-125 °C
Nominal voltage U0	300 V
Number of cores	3
Outer diameter approximate	8 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Tinned
Min. permitted bending radius, moving application/free movement	120.0 mm
Min. permitted bending radius, stationary application/permanent installation	32.0 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	TRUE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® HEAT 125 C MC 3G1 priključni kabel; 3G1; U 0 /U: 300/500 V; polimerni spoj umrežen elektronskim snopom; identifikacija jezgre: boje; zaštićen; -55°C - 125°C; fleksibilan

Ovaj tekst je strojno preveden.
