Upravljački vodovi

LAPP kontrolni vod 1024423/100 100 m

Kataloški br:: 3476129 - 62
Oznaka:: 1024423/100
EAN:: 4044777070954

(0)

Kataloški br:: 3476129 - 62
Oznaka:: 1024423/100
EAN:: 4044777070954

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

-5 %

1,845.00 KM1,940.00 KM

Štedite 95.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Proizvođač-br. dijela	1024423/100
Tip	ÖLFLEX® HEAT 125 C MC 2X1,5
Nominal cross section conductor	1.5 mm²
Material core insulation	Other
Core identification	Colour
Nominal voltage U	750 V
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-55-125 °C
Nominal voltage U0	450 V
Number of cores	2
Outer diameter approximate	8.6 mm
With protective conductor	FALSE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Tinned
Min. permitted bending radius, moving application/free movement	129.0 mm
Min. permitted bending radius, stationary application/permanent installation	34.4 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	TRUE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® HEAT 125 C MC 2x1,5 priključni kabel; 2x1,5; U 0 /U: 450/750 V; polimerni spoj umrežen elektronskim snopom; identifikacija jezgre: boje; zaštićen; -55°C - 125°C; fleksibilan

Ovaj tekst je strojno preveden.
