Upravljački vodovi

LAPP kontrolni vod 1249502/100 100 m

Kataloški br:: 3476185 - 62
Oznaka:: 1249502/100
EAN:: 4044777172733

(0)

Kataloški br:: 3476185 - 62
Oznaka:: 1249502/100
EAN:: 4044777172733

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

120.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Proizvođač-br. dijela	1249502/100
Tip	ÖLFLEX® HEAT 180 SiF A 1x0,5 GNYE
Nominal cross section conductor	0.5 mm²
Material core insulation	Other
Nominal voltage U	1 kV
Conductor material	Copper
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-50-180 °C
Nominal voltage U0	0.6 kV
Number of cores	1
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	2.4 mm
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Tinned
Min. permitted bending radius, stationary application/permanent installation	14.4 mm
Specification core insulation	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Circuit integrity according to BS 6387 CWZ	FALSE
Circuit integrity according to EN 50200 annex E	FALSE
Circuit integrity according to BS 8434-2	FALSE
Circuit integrity according to BS 8491	No
Circuit integrity according to IEC 60331-21	FALSE
Flame retardant according to EN 60332-1-2	TRUE
Flame retardant according to EN 60332-3-21 (Cat A F/R)	FALSE
Flame retardant according to EN 60332-3-22 (Cat A)	FALSE
Flame retardant according to EN 60332-3-23 (Cat B)	FALSE
Flame retardant according to EN 60332-3-24 (Cat C)	FALSE
Flame retardant according to EN 60332-3-25 (Cat D)	FALSE
Halogen free according to EN 60754-1	TRUE
Halogen free according to EN 60754-2	FALSE
Halogen free according to EN 60754-3	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® HEAT 180 SiF A 1x0,5 GNYE jednožilni; 1x0,5; zeleno-žuti; U 0 /U: 0,6/1 kV; silikon; -50°C - 180°C; UL priznato; fiksna instalacija

Ovaj tekst je strojno preveden.
