LAPP kontrolni vod 3 x 0.75 mm² 1123033/100 100 m

Kataloški br:: 3388263 - 62
Oznaka:: 1123033/100
EAN:: 4044774595726

(0)

Kataloški br:: 3388263 - 62
Oznaka:: 1123033/100
EAN:: 4044774595726

Dostupno online (Skladište: Njemačka)

Dostava: 22.12.2025 do 28.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

345.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Presjek	3 x 0.75 mm²
Poprečni presjek (po žili)	0.75 mm²
Proizvođač-br. dijela	1123033/100
Tip	ÖLFLEX® CLASSIC 130 H 3G0,75
Nazivni napon	500 V
Vanjski Ø	5.8 mm
Nazivni napon U0	300 V
Broj žica	3 x
Nominal cross section conductor	0.75 mm²
Material core insulation	Other
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	3
Outer diameter approximate	5.8 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	TRUE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Dca
Reaction-to-fire according to EN 13501-6: Smoke production	s1b
Reaction-to-fire according to EN 13501-6: Acidity	a1
AWG size	Other
Min. permitted bending radius, moving application/free movement	87.0 mm
Min. permitted bending radius, stationary application/permanent installation	23.2 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® CLASSIC 130 H 3G0.75 upravljački kabel; 3G0.75; U 0 /U: 300/500 V; HFFR; Identifikacija žice: brojevi; UL priznat; fleksibilan

Ovaj tekst je strojno preveden.
