LAPP kontrolni vod 4 x 0.5 mm² 0012802/100 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 22.12.2025 do 28.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

Cijena na upit

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Presjek	4 x 0.5 mm²
Poprečni presjek (po žili)	0.5 mm²
Proizvođač-br. dijela	0012802/100
Tip	ÖLFLEX® 440 P 4G0,5
Nazivni napon	500 V
Vanjski Ø	6.6 mm
Nazivni napon U0	300 V
Broj žica	4 x
Nominal cross section conductor	0.5 mm²
Material core insulation	Other
Core identification	Numbers
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-50-90 °C
Nominal voltage U0	300 V
Number of cores	4
Outer diameter approximate	6.6 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Tinned
Min. permitted bending radius, moving application/free movement	82.5 mm
Min. permitted bending radius, stationary application/permanent installation	26.4 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod
