LAPP kontrolni vod 4 x 95 mm² 0011207/750 750 m

(0)

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

224,420.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	750 m
Presjek	4 x 95 mm²
Poprečni presjek (po žili)	95 mm²
Proizvođač-br. dijela	0011207/750
Tip	ÖLFLEX® 191 4G95
Nazivni napon	500 V
Vanjski Ø	47.2 mm
Nazivni napon U0	300 V
Broj žica	4 x
Nominal cross section conductor	95 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Nominal voltage U0	300 V
Number of cores	4
Outer diameter approximate	47.2 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
AWG size	000
Min. permitted bending radius, moving application/free movement	708.0 mm
Min. permitted bending radius, stationary application/permanent installation	188.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod
