Upravljački vodovi

LAPP kontrolni vod 7 x 6 mm² 1119607/500 500 m

Kataloški br:: 3388233 - 62
Oznaka:: 1119607/500
EAN:: 4044774554327

(0)

Kataloški br:: 3388233 - 62
Oznaka:: 1119607/500
EAN:: 4044774554327

Dostupno online (Skladište: Njemačka)

Dostava: 22.12.2025 do 28.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

14,720.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Presjek	7 x 6 mm²
Poprečni presjek (po žili)	6 mm²
Proizvođač-br. dijela	1119607/500
Tip	ÖLFLEX® CLASSIC 110 7G6
Nazivni napon	500 V
Vanjski Ø	16 mm
Nazivni napon U0	300 V
Broj žica	7 x
Nominal cross section conductor	6 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	7
Outer diameter approximate	16 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, moving application/free movement	160.0 mm
Min. permitted bending radius, stationary application/permanent installation	64.0 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® CLASSIC 110 7G6 upravljački kabel; 7G6; U 0 /U: 300/500 V; PVC; Identifikacija žice: brojevi; fleksibilan; VDE registarski broj: 7030

Ovaj tekst je strojno preveden.
