Schneider Electric ATS01N106FT mekani pokretač Snaga motora bei 400 V 3 kW

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 13.07.2025 do 15.07.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

495.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Proizvođač-br. dijela	ATS01N106FT
Tip	ATS01N106FT
dim.	(Š x V x D) 23 x 100 x 100 mm
Dubina	100 mm
Visina	100 mm
Širina	23 mm
Snaga motora bei 400 V	3 kW
Function	Single direction
With display	FALSE
Degree of protection (IP)	IP20
Release class	Other
Rated operation current Ie at 40 °C Tu	6 A
Rated power three-phase motor, inline, at 230 V	0.75 kW
Rated power three-phase motor, inline, at 400 V	2.2 kW
Rated surrounding temperature without derating	40 °C
Integrated motor overload protection	FALSE
Voltage type for actuating	AC/DC
Internal bypass	TRUE
Torque control	FALSE
Vrsta proizvoda	mekani pokretač
